| Item | Parameter | Localization Adaptation Note |
|---|---|---|
| System Name | High-End Proportional Valve Performance Calibration Tool | Preloaded calibration routines aligned with local industrial machinery hydraulic component acceptance specifications |
| Test Pressure Range | 0 ~ 42 MPa | MPa / psi dual display; optional local accredited traceable calibration certificate |
| Control Signal Input | 0~10V, 4~20mA, CANopen | Compatible with mainstream proportional valve communication protocols widely adopted in target market |
| Flow Measurement Range | 0.1 ~ 150 L/min | Tuned for industrial proportional directional, pressure and flow control valves |
| Measurement Accuracy | Pressure ±0.09% FS; Flow ±0.12% FS; Signal ±0.02% FS | Stable operation within local factory ambient temperature range of 12~42℃ |
| Data Sampling Rate | 3500 Hz | Ultra-high-speed sampling for dynamic signal-response curve recording required by local third-party audits |
| Test & Calibration Modes | Gain calibration, hysteresis test, frequency response, step response, zero drift & leakage test | Multi-language HMI; customizable report templates matching local industrial quality documentation standards |
| Power Supply | 380V / 415V, 50Hz | Matches standard power configuration of local precision component workshops |
| Working Medium | ISO VG32 / VG46 hydraulic oil | Compatible with locally supplied premium hydraulic fluid for precision test benches |
| Protection Grade | IP54 | Dust and splash protection for clean precision hydraulic component calibration workshops |
| Target B-type Buyer | Local Application Scenario | Local Pain Points | Product Advantages (Quantitative Data) |
|---|---|---|---|
| Proportional valve OEM | End-of-line calibration and quality inspection for finished proportional valves | Legacy testing machinery takes 13 mins per valve; hysteresis test deviation reaches 2.7% | Reduce single valve calibration cycle to 3.1 mins; measurement deviation ≤0.12% FS; support continuous 18h unattended batch calibration |
| Industrial automation Tier1 integrator | Pre-commissioning calibration for assembled hydraulic proportional control modules | Difficult to capture high-frequency step response curves; OEM audit reports frequently rejected | Precision performance calibration system auto-saves 11,000+ groups of curve data; one-click report export; audit approval rate improved by 88% |
| Independent industrial test laboratory | Type testing and performance certification for newly developed proportional valve prototypes | Conventional hydraulic testing equipment requires manual signal reconfiguration when switching valve models | proportional valve calibrator; valve model switching time reduced by 83%; 32 pre-stored standard calibration recipes |
| Hydraulic system service & retrofit workshop | On-bench recalibration for repaired proportional hydraulic valves | Minor gain drift and hysteresis defects cannot be identified by static tests; 3.6% post-retrofit system control failure rate | proportional valve calibration tool detects signal drift as low as 0.02%; quantifies hysteresis error; reduce field control failure rate by 51% |
Produsen komponen hidraulik presisi tinggi regional yang mengkhususkan diri pada katup proporsional untuk cetakan injeksi dan mesin pembentuk logam, memasok komponen hidraulik ke integrator sistem otomasi lokal. Sebelumnya, mereka menggunakan mesin pengujian yang lebih tua untuk kalibrasi katup dan sering menghadapi keluhan toleransi ketidaksesuaian dari pelanggan hilir.
Komentar klien: Kalibrator katup proporsional ini, alat kalibrasi katup proporsional kami, dan sistem kalibrasi kinerja presisi, meningkatkan peralatan pengujian hidraulik kami. Ini menjamin penyetelan yang tepat pada semua komponen hidraulik dan membantu kami memenuhi persyaratan toleransi ketat dari OEM otomasi.
Jawaban: Mendukung penguatan, histeresis, respons frekuensi, dan kalibrasi kebocoran untuk katup tekanan, aliran, dan arah proporsional. Kalibrator katup proporsional ini, juga merupakan alat kalibrasi katup proporsional, mencakup sebagian besar komponen hidrolik presisi tinggi yang digunakan dalam mesin otomasi industri.
Jawaban: Ya. Mendukung CANopen, sinyal analog dan protokol ekspor data standar. Tim teknik kami menyediakan komisioning di lokasi untuk mengintegrasikan peralatan pengujian hidraulik ini dengan MES atau database kualitas pabrik Anda.
Jawaban: Profil pemuatan sinyal khusus, batas toleransi, dan templat laporan kalibrasi siap audit tersedia. Kami dapat menyesuaikan alur kerja alat kalibrasi katup proporsional untuk mematuhi standar kepatuhan mesin industri regional.
Hubungi tim teknik kalibrasi hidraulik kami hari ini untuk mendapatkan penawaran khusus dan video demo peralatan. Bagikan spesifikasi katup proporsional dan persyaratan audit lokal Anda, dan kami akan mengatur konsultasi teknis gratis dalam waktu 24 jam.
