| Item | Specification | Localization Adaptation Note |
|---|---|---|
| Testable Units | Gear pumps, vane pumps, piston pumps; orbital motors, radial and axial piston hydraulic motors | Metric mounting flanges; adapters fit hydraulic components widely deployed in Portuguese construction, forestry and marine auxiliary machinery |
| Adjustable Test Pressure | 0 ~ 42 MPa | CE certified pressure transducers; dual overpressure protection compliant with Portuguese NP industrial safety directives |
| Rotational Speed Range | 0 ~ 3400 rpm | VFD closed-loop speed regulation; supports stepped, ramped and constant speed working condition simulation |
| Torque Measurement | 0 ~ 2000 N·m | High stability torque sensor; continuous data capture for NP quality traceability audits |
| Flow Measurement | 0 ~ 600 L/min | Flow meter accuracy ±0.41% FS; automatic oil temperature compensation to offset viscosity variation |
| Control & Data Export | Industrial touch HMI, saved custom test recipes, PDF / CSV curve reports | English operation interface; editable report templates matching local third-party machinery inspection standards |
| Power Input | 400V 3-phase 50Hz | Fully compatible with Portuguese industrial power grids; built-in voltage fluctuation suppression |
| Enclosure Protection | IP54 | Dust and splash resistance; optimized ventilation to cope with hot summer factory conditions |
| Brand | SCLON Test Equipment | EU local technical coordination available for commissioning of Hydraulic equipment testing setup, Hydraulic component testing machine and Hydraulic pump and motor test rig |
| Target Buyer Type | Local Application Scenario | Local Pain Point | Product Quantifiable Advantages |
|---|---|---|---|
| Hydraulic Component Manufacturer | End-of-line batch Quality Hydraulic Testing for newly produced pumps and motors | Frequent fixture replacement between pump and motor testing wastes production time | Hydraulic pump and motor test rig reduces fixture switching time by 46%; daily batch inspection capacity rises significantly |
| Forestry Machinery Overhaul Shop | Post-rebuild validation for hydraulic pumps and motors used in log loaders | Static testing fails to replicate fluctuating loads from forest terrain; hidden defects trigger field breakdowns | Hydraulic equipment testing setup simulates variable cyclic loads; post-rebuild field failure incidents reduced by 68% |
| Marine Hydraulic Parts Supplier | Pre-shipment inspection of hydraulic assemblies for small coastal vessels | Manual testing lacks complete performance records; marine clients reject shipments without certified data | Hydraulic component testing machine generates permanent tamper-proof test reports; shipment rejection rate cut by 75% |
| Independent Hydraulic Testing Laboratory | Outsourced component performance verification for multiple local machinery clients | Separate single-function test rigs occupy large floor space and increase maintenance workload | Combined Hydraulic Pump Test Bench and Hydraulic Motor Test Bench reduces total occupied workshop area by 39% |
A1: Ya. Sebagai pengaturan pengujian peralatan Hidraulik dan mesin pengujian komponen Hidraulik, rig pengujian pompa dan motor Hidraulik ini mengintegrasikan Bangku Uji Pompa Hidraulik dan Bangku Uji Motor Hidraulik. Ini dapat mensimulasikan beban berfluktuasi di dunia nyata, mencatat kurva kinerja penuh dan mengekspor laporan pengujian formal yang dapat dilacak.
A2: Ya. Kami menyediakan commissioning di lokasi, pelatihan operator praktis, garansi 12 bulan, dan dukungan pemecahan masalah jarak jauh yang cepat untuk Bangku Uji Pompa Hidraulik dan Bangku Uji Motor Hidraulik Anda.
A3: Ekspansi modular didukung. Kami dapat menambahkan sensor tambahan, merancang perlengkapan pemasangan yang dipesan lebih dahulu, dan memprogram rangkaian pengujian baru. Kirimkan daftar komponen dan spesifikasi pengujian Anda untuk menerima pengaturan pengujian peralatan Hidraulik yang disesuaikan dan penawaran harga mesin pengujian komponen Hidraulik.
Siap untuk meningkatkan bengkel Anda dengan Peralatan Uji SCLON yang tangguh untuk Pengujian Hidraulik Berkualitas yang efisien? Kirimkan model pompa dan motor Anda serta persyaratan uji beban hari ini. Tim teknik kami akan menyiapkan kutipan khusus dan gambar tata letak untuk pompa Hidraulik dan rig pengujian motor Anda, pengaturan pengujian peralatan Hidraulik, dan mesin pengujian komponen Hidraulik.
