| Parameter | Details | Localization Adaptation Note |
|---|---|---|
| Simulation Function | Dynamic pressure fluctuation, flow rate variation, cyclic load, temperature cycling test | Simulates real working conditions of vehicle hydraulic circuits, matching SAE and ISO automotive hydraulic system standards |
| Pressure Range | 0 ~ 80 MPa, adjustable resolution: 0.005 MPa | Pressure sensors traceable to local metrology bodies; calibration certificates available for factory audits |
| Flow Rate Test Range | 0.1 ~ 120 L/min | Wide flow coverage for passenger car and commercial vehicle hydraulic valve assemblies popular in target markets |
| Temperature Control | 20 ~ 120 ℃ hydraulic oil temperature control | Temperature module replicates under-hood thermal environment required for EU and US automotive component validation |
| Data Acquisition | 1000Hz multi-channel synchronous sampling | Collects pressure, flow and temperature signals simultaneously for complete system-level valve assessment |
| Operating Interface | PLC + 12-inch touchscreen, multi-language support | English, German, French UI preloaded for international engineering and QC teams |
| Report Export | PDF / CSV, customizable test templates | Output reports accepted by local third-party automotive certification organizations |
| Safety Configuration | Overpressure shutdown, over-temperature alarm, oil leakage monitoring, safety interlock door | Safety framework compliant with local machinery directives for industrial hydraulic test stations |
| Target B-type Buyer | Local Application Scenario | Local Pain Point | Product Advantages (Quantitative Data) |
|---|---|---|---|
| Automotive Hydraulic System Tier1 Supplier | System-level validation of assembled hydraulic valve modules before vehicle integration | Static-only testing misses thermal and flow-related defects; 3.6% of valve modules fail field trials | This precision valve test equipment simulates real vehicle conditions; field failure rate reduced to 0.17%; validation coverage improved by 93% |
| Vehicle OEM R&D Center | Durability and performance verification for new hydraulic valve system prototypes | Static bench testing cannot replicate cyclic hydraulic shocks; each validation cycle takes 28 hours | Our best valve test bench cuts full dynamic validation cycle to 6.2 hours; prototype evaluation speed increased by 78% |
| Hydraulic Valve System Component Factory | Batch reliability testing for mass-produced hydraulic valve assemblies | Manual setup causes inconsistent test environments; 22% of test results show poor repeatability | SCLON Valve Tester auto-calibrates test conditions; test result repeatability boosted to 99.5% |
| Independent Automotive System Certification House | Third-party witnessed testing for hydraulic valve system compliance | Old equipment lacks synchronized multi-channel data; 31% of submitted test reports get rejected | High-quality valve testing generates synchronized multi-parameter records; report rejection rate decreased by 85% |
Profil Pelanggan : Integrator sistem hidraulik otomotif tingkat 1 di Michigan, AS, yang memasok rakitan katup hidraulik lengkap untuk truk komersial tugas menengah. Situasi Asli : Perusahaan mengandalkan bangku uji tekanan statis dan tidak dapat mensimulasikan variasi suhu dan aliran di dunia nyata selama validasi sistem katup.
A1: Ya. Peralatan uji katup presisi kami mengontrol tekanan, aliran, dan suhu oli secara serempak untuk meniru lingkungan kerja kendaraan. Ini mendukung pengujian katup berkualitas tinggi untuk rakitan katup hidrolik lengkap.
A2: Tentu saja. Insinyur dapat memprogram kurva tekanan dan aliran siklik khusus pada HMI. Tim kami dapat memuat profil uji standar terlebih dahulu ke bangku uji katup terbaik berdasarkan spesifikasi sistem kendaraan Anda.
A3: Ya. Sistem ini mencatat data multi-saluran dengan stempel waktu dan mengekspor laporan PDF yang tahan terhadap kerusakan, sepenuhnya kompatibel dengan persyaratan audit pihak ketiga otomotif lokal.
Hubungi tim teknik uji hidraulik kami hari ini untuk mendiskusikan persyaratan validasi dinamis sistem katup Anda. Bagikan spesifikasi rakitan katup dan profil kondisi pengoperasian Anda, dan kami akan memberikan penawaran harga khusus dan rencana perlengkapan untuk Peralatan Uji Hidraulik Tingkat Lanjut Anda.
